Technical Specifications
|
|
Print head
|
8-16Konica Minolta
|
Print modes
|
Speed mode: 67sqm/hr
Production mode: 48sqm/hr
Quality mode: 36sqm/hr
Ultra Quality: 24sqm/hr
|
Print resolution
|
Up to 1440x1440dpi
|
Technology
|
Piezoelectric inkjet,UV-curable inks; Greyscale technology.
|
Ink cartridge colors
|
CMYK,LC,LM,W(optional),V(optional);
|
Ink types
|
UV-curable,pigment-based ink
|
Ink cartridge size
|
4liter(CMYK,LC,LM,W,V);
|
Rip software
|
Photoprint Flora Edition,Onyx(Optional);
|
Color management
|
ICC based color,adjustment curves,density adjustment
|
File formats
|
TIFF,JPEG,Postscript,EPS,PDF,etc
|
Handling
|
Flatbed,sheet feed,and roll feed with optional
Roll-to-Roll upgrade kit.True vacuum table,
automatic media registration pin system
for easy loading and accurate printing step.
With optional pump blow make it easy to unload media;
|
Rigid media support
|
Standard true flatbed table support rigid materials
up to 254x122cm,50kg/sqm
|
Roll-feed media support
|
Optional Roll-to-Roll upgrade kit supports flexible media
up to 250cm wide,with a roll dimension 30cm,up to 100kg in weight
|
Thicdness
|
Up to 100mm;
|
Connectivity
|
|
Interfaces(standard)
|
Fast standard USB port
|
UV energy source
|
|
|
Dual shuttered UV lamps,Independent user selectable
control of shutter aperture and two lamp power level
|
Dimensions(lxwxh)-Printer
|
480x260x144cm;Shipping:500x246x150cm
|
Weight
|
2000kg.
|
Operating conditions
|
|
Temperature
|
20to30°c;
|
Relative Humidity
|
20%-80%,non-condensing(with synthetic media 40%
minimum recommended to avoid static electricity;with paper-based media60% maximum recommended to avoid buckling
|
Power
|
|
Maximum
|
8500watts
|
Requirements
|
Input voltage:200to 240VAC,signal-phase,50/60Hz,32A max
|
Warranty
|
One year limited warranty.
(Please consult your local dealer for accurate data)
|
