Technical Specifications

●Print head: 8-16Konica Minolta or4-8Spectra Polaris Piezoelectric Print Heads

●Print modes:Standard quality:Konica Minolta  38.8sqm/hr    Spectra Polaris   26sqm/hr; High

●quality:Konica Minolta  25.8sqm/hr   Spectra Polaris    18sqm/hr;Ultra quality  Konica Minolta       19.4sqm/hr    Spectra Polaris    13.5sqm/hr;

●Technology:Piezoelectric inkjet,UV-curable inks;

●Ink cartridge colors:CMYK,LC,LM,W,V;

●Ink types:UV-curable,pigment-based ink;

●Ink cartridge size:4liter(CMYK,LC,LM,W,V);

●Rip software:Photoprint Flora Edition,Onyx(Optional);

●Color managemet:ICC based color,adjustment curves,density adjustment;

●File formats:TIFF,JPEG,Postscript,EPS,PDF,etc;

●Handling:Flatbed,sheet feed,and ross feed with optiional Roll-to-Roll upgrade kit.True vacuum table,automatic media registration pin system for easy loading and accurate printing step.With optional pump blow make it easy to unload media

●Rigid media support:Standard true flatbed table support rigid materials up 254x122cm,50kg/sqm;

●Roll-feed media support:Optional Roll-to-Roll upgrade kit supports flexible media up to 250cm wide,with a roll diminsion 30cm,up to 100kg in weight;

●Thicdness: Up to 100mm;

●Dimensions(lxwxh  )Printer:480x260x144cm;Shipping:500x216x150cm;

●Weight:1600kg.

●Temperature:20to30°c;

● Maximum:7500watts;   Speciality inks for glass,acrylic,vaccum forming&more.
